You have 3 options which are: Hinge/Pull side mount (hinge side) Parallel Arm push side mount (non- hinge side) Over door/Transom push side mount (non- hinge side) Fitting instructions for all 3 options are included with the closer, determine what side of the door to mount the closer and use appropriate instructions.

The following items may cause the exit devices top latch from being held in the retracted position. 1. The top or bottom rods are out of adjustment. 2. The top latch hold back feature is defective. 3. The top latch might be a pullman latch which has no hold back feature. Following exit devices 2227/F, 33/3527A/F, 33/3547A/48A/F, 98/9927/F and 98/9947/48/F have similar rod adjustment procedures. All top latches control the bottom latch assemblies. When door is in open position top latch should stay in retracted position and bottom latch should be held up by top latch being held in retracted position. If top latch is not staying retracted follow the installation instruction rod adjustment procedure.33/3547A Rod adjustment 2227 Rod adjustment 98/9927/F Rod adjustment 33/3527A/F Rod adjustment 98/9947 Rod adjustment 98/9947WDC Rod adjustment

Cylindrical Locks: a bored lockset whose latch or bolt locking mechanism is contained in the portion installed through the cross-boreMedium, high to extra heavy duty Commercial, multi-family and institutional applications Pros - Heavy duty, unlimited cylinder options Cons - Large rose (larger footprint on face of door), limited lever designs Cylindrical locks with levers usually require a spring cage to lift the lever and keep it horizontal. These spring cages lead to a bigger rose (circular, finished plate against the door) – typically around 3.5 inches in diameter. Knob designs do not require this extra spring force and these roses usually have a diameter around 2.5 inches. Schlage Commercial cylindrical locks· Heavy Duty (high use, high abuse applications - educational facilities, hospitals, etc.) D-Series – knob style (ANSI/BHMA Certified A156.2-2003, Series 4000, Grade 1, UL Listed for 3-hour fire door ND-Series – lever style (ANSI/BHMA Certified A156.2-2003, Series 4000, Grade 1, UL Listed for 3-hour fire door)· Standard Duty A-Series - knob style (ANSI/BHMA Certified A156.2-2003, Series 4000, Grade 2, UL Listed for 3-hour fire door) AL-Series – lever style (ANSI/BHMA Certified A156.2-2003, Series 4000, Grade 2, UL Listed for 3-hour fire door) Falcon cylindrical locks· Heavy Duty (high use, high abuse applications - educational facilities, hospitals, etc.) X-Series – knob style (ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour fire door) T-Series – lever style (ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour fire door)· Standard Duty W-Series – knob and lever style (ANSI A156.2, Series 4000, Grade 2, UL Listed for 3-Hour fire door) B-Series – lever style (ANSI A156.2, Series 4000, Grade 2, UL Listed for 3-Hour fire door

A Master keying system regulates access to specific zones and all locks can be operated by a single master-key, this involves each lock being individual pinned up so only certain keys will operate those locks.

Re-keying means changing/replacing the pins in an existing lock so that only a new key can open it, this is recommended if you move into a home or business that was previously occupied by someone else. A Master Key System comprises of a hierarchy of keys with a master key that will operate all locks.
